ZH-878-3/S solar low intensity of B type duplex obstacle lamp
ZH-878-3/S solar low intensity of B type double barrier for red light flash aviation obstacle light. Using solar power, no power transmission cables, especially suitable for the cable laying difficulties, lack of power supply place. The height of the building and conventional B type lamp the same intensity. Solar energy lamp had to use in sunny places, such as above the other object blocking the sunlight place is not suitable for installation.
Product introduction:
ZH-878-3/S solar low intensity of B type double barrier for red light flash aviation obstacle light. Using solar power, no power transmission cables, especially suitable for the cable laying difficulties, lack of power supply place. The height of the building and conventional B type lamp the same intensity. Solar energy lamp had to use in sunny places, such as above the other object blocking the sunlight place is not suitable for installation.
Product description:
● lamp adopts SUS304 stainless steel, the two obstacle lights integrated installation as one of the double red light aviation obstacle light.
The solar battery board adopts the international advanced, low intensity, high efficiency battery plate, with the solar energy battery for deep cycle for power. Panels and low iron tempered glass sealing, high stability.
The battery charge and discharge using the power of advanced management system, comprehensive protection, overvoltage, floating in the battery voltage, temperature of various aspects, greatly improving the service life of the battery.
The control circuit adopts the flash controller with micro power consumption, reduce energy consumption control circuit itself, greatly improves the reliability of the products.
The LED light source, using imported international advanced long life, low power consumption, high efficiency of the chip package (longer than 100000 hours).
● shell structure made of stainless steel and aluminum alloy composition, earthquake resistance, corrosion resistance.
● lampshade adopts PC material, has excellent impact resistance (IZOD notched impact strength: 90), thermal stability (high temperature of 130 ℃), good light transmission (transmission rate up to 90%), anti UV, anti aging. Light rain days of continuous work time more than 15 days.
The General Administration of civil aviation of China license number: 07404510
The General Administration of civil aviation of China designated inspection units (the State Quality Supervision Inspection Center) test certificate no.:
The product model:
● ZH-878-3/S: single lamp solar low intensity of B type duplex disorder, with light operated switch, no controller, automatic control on the fuse can be installed, each lamp are used alone. The lamp comprises 2 groups of lamp holder, mutual backup. When the lamp cap damage working immediately when the automatic transfer to another lamp work.
